Hose inner Ø (ins) | 1/4 || DN Ø ins | 1/4 || Thread size (R1) | 1/8 || Related products | 112564,116651 || Hex1 (mm) | 14 || Fitting | 2 Piece Fitting || Reference | 241000204 || L1 (mm) | 28 || C Ø (mm) | 4 || L (mm) | 43 || Barcode EAN13 | 5023495265322 || Hose inner Ø (mm) | 6.3 || DN Ø mm | 6.3 || Cone angle | 60° || Tariff Code | 7307199000 || Thread type | BSP || Nominal I.D. | DN06 || Thread Male or Female | Female Thread || Barcode 128 | S.26532 || Position | Straight Swivel || Returnable Product | This item can be returned
Barcode 128
S.26532
Barcode EAN13
5023495265322
Brand
Dicsa
Cone angle
60°
C Ø (mm)
4
DN Ø ins
1/4
DN Ø mm
6.3
Fitting
2 Piece Fitting
Hex1 (mm)
14
Hose inner Ø (ins)
1/4
Hose inner Ø (mm)
6.3
L (mm)
43
L1 (mm)
28
Nominal I.D.
DN06
Position
Straight Swivel
Product Family
Sparex
Reference
241000204
Related products
Dicsa 2SN/2SC 2 Wire Ferrule 1/4''S.112564https://22df4504011deb964a17-39bee0485bf754a0e77a8d4deb668d89.ssl.cf4.rackcdn.com/imagelibrary_sml/112564_pic1.jpgDicsaDicsa Ferrule 1/4'' 4SP 4 WireS.116651https://22df4504011deb964a17-39bee0485bf754a0e77a8d4deb668d89.ssl.cf4.rackcdn.com/imagelibrary_sml/116651_pic1.jpgDicsaL mm 30L1 mm 26C Ø mm 11.4D Ø mm 22E Ø mm 15.8S.112564, S.116651
Tariff Code
7307199000
Thread Male or Female
Female Thread
Thread size (R1)
1/8
Thread type
BSP
Comparison Table
Suitable For Make/Model
Suitable For Make/Model
This product is not associated with any particular make or model
OEM Part Numbers
Oem Part Numbers
This product is not associated with any particular OEM part number
